WWC Machlink Instrumentation Cable 6 Triad 0.5mm 110/150V Copper/PVC/Ind & Overall Screen/SWA/PVC Black

Description

Instrumentation Cable Armoured, 0.5 mm, Class 2 Annealed Copper, 110 Volt AC/150 Volt DC, 6 Triad, 7/0.3 mm Strands, Individual & Overall Screened Screen, 18 mm Overall Diameter, 340 mm During Installation/227 mm After Installation Bend Radius, 0.4 mm Insulation Thickness, 38.4 Ohm/km Conductor Resistance, Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire Screen, Galvanised Steel Wire Armour, Black/White/Red Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, -25 to 75 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1

Key Specifications

SKU	WWC5363N
Brand	WWC
Product Type	Instrumentation Cable Armoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	5363N
Armour Material	Galvanised Steel Wire
Bend Radius	340 mm During Installation/227 mm After Installation
Conductor Resistance	38.4 Ohm/km
Conductor Size	0.5 mm
Conductor Type	Class 2 Annealed Copper
Insulation Material	V-90 PVC
Core Colours	Black/White/Red
Insulation Thickness	0.4 mm
Number of Pairs	6 Triad
Overall Diameter	18 mm
Screen Format	Individual & Overall Screened
Screen Material	Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1
Sheath Colour	Black
Sheath Material	5V-90 PVC
Stranding	7/0.3 mm
Temperature	-25 to 75 deg C
Voltage	110 Volt AC/150 Volt DC
