Utilux Pin Connector Insulated Double Grip Circular 0.5-1.5mm Red

Description

Pin Connector Insulated Double Grip Circular, 0.5-1.5 mm, 76B 11C 11B 99 102 120, Copper, Red Insulation, 3.5 mm Insulation Diameter, Tin Electroplated, 10.3 mm Barrel Length, 9.5 mm Pin Length, 21 mm Overall Length, 1.6 mm Width

Key Specifications

Barcode (EAN-13)	9313988011472
SKU	UTIH2286/100
Brand	Utilux
Range Name	UtiLug SuperGrip
Product Type	Blade & Pin Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Electro tinned copper to minimise corrosion Fitted with a copper ferrule and pre-insulated for secure insulation support
Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	UTIH2286/100
Barrel Length	10.3 mm
Crimping Die	76B 11C 11B 99 102 120
Conductor Size	0.5-1.5mm
Finish	Tin Electroplated
Insulation Diameter	3.5 mm
Insulation Colour	Red
Material	Copper
Pin Length	9.5 mm
Overall Length	21 mm
Width	1.6 mm
