Tycab Ordinary Duty Flexible Cable 3 Core & Earth 2.5mm 250/440V Plain Copper PVC/PVC Grey

Description

Flexible Cable, 2.5 mm, Oxygen Free Copper, 250-440 Volt, 20 Amp, 3 Core + Earth, 50/0.25 mm Strands, 11.2 mm Overall Diameter, 0.8 mm Insulation Thickness, 1.1 mm Sheath Thickness, 8 Ohm/km Conductor Resistance, Brown/Blue/White/Green/Yellow Core, V-90 PVC RoHS Complaint Insulation, 5V-90 PVC RoHS Compliant Sheath, Grey Sheath, 60 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 3008.1.1:2009

Key Specifications

Barcode (EAN-13)	9320943153481
SKU	TYCFRM450025-SY-100
Brand	Tycab
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	FRM450025-SY-100
Conductor Resistance	8 Ohm/km
Conductor Size	2.5 mm
Conductor Type	Oxygen Free Copper
Core Colours	Brown/Blue/White/Green/Yellow
Current	20 Amp
Insulation Material	V-90 PVC RoHS Complaint
Insulation Thickness	0.8 mm
Number of Cores	3 Core + Earth
Overall Diameter	11.2 mm
Sheath Colour	Grey
Sheath Material	5V-90 PVC RoHS Compliant
Sheath Thickness	1.1 mm
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 3008.1.1:2009
Stranding	50/0.25 mm
Temperature	60 deg C
Voltage	250-440 Volt
