Schneider Circuit Breaker Motor Rated 3Pole 14A 5.5kW 690VAC DIN Rail Clipped Mount

$Schneider\Schneider_GV2ME.jpg$

Description

Motor Rated Miniature Circuit Breaker, 690 Volt, 14 Amp, 50/60 Hz, 15 kA Interrupt Capacity, 170 Magnetic Rating, 5.5 kW, 3 Pole, Toggle Operator, Screw Clamp Terminal, 100000 Cycles, IP20, DIN Rail Mounting, 20 to 60 deg C, 89 mm Height, 45 mm Width, 78.5 mm Depth

Key Specifications

Barcode (EAN-13)	3389110343175
SKU	TEEGV2ME16
Brand	Schneider
Range Name	GV2ME
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	GV2ME16
Depth	78.5 mm
Current	14 Amp
Frequency	50/60 Hz
Interrupt Capacity	15 kA
IP Rating	IP20
Height	89 mm
Load Rating	5.5 kW
Magnetic Rating	170
Mounting Method	DIN Rail
Operating Cycles	100000 Cycles
Number Of Poles	3 Pole
Operator Type	Operators
Temperature	20 to 60 deg C
Terminal Type	Screw Clamp
Voltage	690 Volt
Width	45 mm
