Schneider Contactor Control Relay Switching 2 Pole 10A 24VDC 1NO-1NC DIN Rail/Plate Mount

Description

Contactor Control Relay Switching, AC15 Rating: 240 Volt AC at 10 Amp, 24 Volt DC, 1NO+1NC, 2 Pole, Operating Time: 4-6, 8-12 ms NO, 6-8, 10-18 NC, Screw Clamp, DIN Rail/Base/Plate Mount, IP2x, -25 to 50 deg C, 56 mm Height, 27 mm Width, 55.5 mm Depth

Key Specifications

Barcode (EAN-13)	3389110564235
SKU	TEECA3SK11BD
Brand	Schneider
Range Name	TeSys Model SK
Product Type	Contactors Switching

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CA3SK11BD
Contact Configuration	1 Normally Opened & 1 Normally Closed
AC15 Rating	10 Amp 240 Volt
Height	56 mm
Depth	55.5 mm
IP Rating	IP2x
Mounting Method	DIN Rail/Base
Operating Coil Voltage	24 Volt DC
Number Of Poles	2 Pole
Operating Time	4-6 8-12 ms NO/6-8 10-18 NC
Temperature	-25 to 50 deg C
Terminal Connection	Screw Clamp
Width	27 mm
