Siemens Protomont XHD Flexible Mining Cable Extra Heavy Duty 2 Core 1.5sq-m Copper 0.6/1kV R-EP-90/PCP Black

Description

Flexible Mining Cable Extra Heavy Duty 2 Core, 1.5 mm, Stranded Tinned Copper, 0.6/1 kV, 2 Core, 30/0.25 mm Strands, Overall Screened, 12.3 mm Overall Diameter, Static 49.2 mm/Flexible 61.5 mm Bend Radius, 15 N/mm, R-EP-90 Elastomer Insulation, Heavy Duty PCP Sheath, Black Sheath, Static -40 to 80 deg C/Flexible -25 to 80 deg C, AS/NZS 3008.1.12017

Key Specifications

SKU	SIE5DL4052
Brand	Siemens
Range Name	Protomont
Product Type	Mining Cable Extra Heavy Duty

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	5DL4052
Bend Radius	Static 49.2 mm Flexible 61.5 mm
Conductor Type	Stranded Tinned Copper
Conductor Size	1.5 mm
Insulation Material	R-EP-90 Elastomer
Number of Cores	2 Core
Overall Diameter	12.3 mm
Sheath Colour	Black
Screen Format	Overall Screened
Sheath Material	Heavy Duty PCP
Standards	AS/NZS 3008.1.1:2017
Stranding	30/0.25 mm
Tensile Strength	15 N/ mm
Voltage	0.6-1 kV
Temperature	Static -40 to 80 deg C/ Flexible -25 to 80 deg C
