Sprecher+Schuh Non-Reversing Contactor 3 Pole 90kW 190A AC3 275A AC1 24-60VAC/DC 1NO-1NC Auxiliary Electronic

$Sprecher\Sprecher_CA9190.jpg$

Description

Non-Reversing Contactor, 24-60 Volt AC/DC, AC3 Rating (kW): 110 at 1 kV, 90 at 415 Volt, 132 at 690 Volt, AC3 Rating (Amps): 85 at 1000 Volt, 190 at 415 Volt, 135 at 690 Volt, AC1 Rating (Amps): 250 at 1 kV, 275 at 690 Volt, 1NO-1NC Auxiliary, 3 Pole, Operating Time: 25-60 ms Closing Delay, 45-80 ms Opening Delay, 196 mm Height, 105 mm Width, Without PLC Interface, Electronic Coil

Key Specifications

SKU	S&SCA91901124W
Brand	Sprecher+Schuh
Range Name	CA9
Product Type	Contactors Non-Reversing

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Simplifies selection with electronic wide range AC/DC coils Saves energy with low power consumption For ease of change over, adaptor plates available in KIT form for CA6 to CA9 migration Several contactor families provide a wide variety of contactor sizes, offering economy and selection Compact dimensions saves panel space
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CA91901124W
AC1 Rating (Amps)	250/275 Amp AC1
AC3 Rating (Amps)	85/190/135 Amp AC3
AC3 Rating (kW)	110/90/132 kW
Contact Configuration	1 Normally Opened & 1 Normally Closed Aux
Height	196 mm
Number Of Poles	3 Pole
Operating Coil Voltage	24-60 Volt AC/DC
Operating Time	25-60 ms Closing/45-80 ms Opening
Please Note	Without PLC Interface Electronic Coil
Width	105 mm
