Radox 155 Flexible Wire Single Insulated 1 Core 2.5mm 0.6/1kV Stranded Tinned Copper XLPE Blue

Description

Flexible Wire, Single Insulated, 1 Core, 2.5 mm, Stranded Tinned Copper, 0.6/1 kV, 50/0.25 mm Strands, 3.5 mm Overall Diameter, 10.5 mm Bend Radius, Conductor Resistance: 8.21 Ohm/km, XLPE Insulation, Unsheathed, Blue Insulation, -55 to 155 deg C

Key Specifications

SKU	RADR155/2.5/BLU
Brand	Radox
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Excellent high and low temperature and ozone resistance Weatherproof Easy to process Flame retardant High resistance to heat pressure High abrasion resistance Soldering resistant Flexible Resistant to impregnation resins and varnishes
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	R155/2.5/BLU
Bend Radius	10.5 mm
Conductor Resistance	8.21 Ohm/km
Conductor Size	2.5 mm
Conductor Type	Stranded Tinned Copper
Insulation Colour	Blue
Insulation Material	XLPE
Overall Diameter	3.5 mm
Number of Cores	1 Core
Sheath Material	Unsheathed
Stranding	50/0.25 mm
Temperature	-55 to 155 deg C
Voltage	0.6-1 kV
