Phoenix Contact Bootlace Ferrule Insulated with Collar 0.75mm 1.3x8mm Pin Blue 14.5mm OAL

Description

Bootlace Ferrule, Insulated with Collar, Conductor Size: 0.75 mm, Number of Conductors: 2, 14.5mm Overall Length, Max. Wire Strip Length: 11mm, Collar Inside Diameter: 2.9mm, Collar Thickness: 0.25mm, Pin Diameter: 1.3mm, Pin Length: 8mm, Pin Thickness: 0.15mm, Distance: 3.7mm, Sleeve Material: Electrolytic Copper, Insulation Material: Polypropylene, Tin Plated Finish, Blue Insulation, Flammability: UL94-HB, 105 deg C, 1000 Pack, with Collar

Key Specifications

SKU	PHO3201547
Brand	Phoenix Contact
Product Type	Bootlace Ferrules

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	The taped ferrules were developed specifically for the crimping machine CF 3000 -2,5 Can be used to wire all terminal blocks, especially those of the CLIPLINE complete system
Standard Pack Size	1000
UNSPSC Class	39121400
UOM	PK
Vendor Product	3201547
Collar Thickness	0.25 mm
Collar Inside Diameter	2.9 mm
Conductor Size	0.75 mm
Finish	Tin Plated
Flammability	UL94-HB
Insulation Colour	Blue
Number of Conductors	2
Pin Diameter	1.3 mm
Pin Length	8 mm
Pack Size	1000 Pack
Overall Length	14.5 mm
Pin Thickness	0.15 mm
Please Note	with Collar
Sleeve Material	Electrolytic Copper
Temperature	105 deg C
Wire Strip Length	11 mm
