Panduit Ring Terminal Insulated Single Grip 4-6mm M10 Stud Yellow 33.3mm OAL

Description

Ring Terminal, Insulated, Single Grip, Conductor Size: 4-6 mm, Stud Size: M10, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Yellow Insulation, Tin Plated Finish, 221 deg F, 33.3mm Overall Length, 16.6mm Lug Length, 14.7mm Lug Width, 1mm Lug Thickness, 9.9mm Lug Inside Diameter, Barrel Length: 13mm, Max. Insulation Diameter: 5.8mm, 25 Pack

Key Specifications

SKU	PANEV10-38RB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV10-38RB-Q
Barrel Length	13 mm
Barrel Type	Funnel
Conductive Material	Copper
Body Material	Copper
Conductor Size	4.0-6.0mm
Insulation Colour	Yellow
Finish	Tin Plated
Lug Inside Diameter	9.9 mm
Insulation Material	Vinyl
Insulation Diameter	5.8 mm
Lug Length	16.6 mm
Lug Thickness	1 mm
Lug Width	14.7 mm
Mounting Method	Free Hanging
Pack Size	25 Pack
Overall Length	33.3 mm
Stud Size	M10 Stud
Seam Type	Butted
Temperature	221 deg F
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
