Olex 2.5mm Flat TPS Cable Black/Red/Green/Yellow 1mtr

Description

Flat TPS Cable, 2.5 mm, Stranded Copper, 450-750 Volt, 2 Core + Earth, 7/0.67 mm Strands, 12.2 mm x 5.4 mm Overall Diameter, 2.5 mm Earth Conductor, 1 mtr Length, 0.7 mm Insulation Thickness, 1 mm Sheath Thickness, DC: 7.41 Ohm/km AC: 9.01 Ohm/km Conductor Resistance, 12 MOhm/km Insulation Resistance, Red/Black/Green/Yellow Core, V-90 PVC Insulation, PVC Sheath, White Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.2

Key Specifications

Barcode (EAN-13)	9322576240521
SKU	OLX7/067-2ERBA1
Brand	Olex
Product Type	Flat TPS Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CNCP07A1002WVAA
Conductor Type	Stranded Copper
Conductor Resistance	DC: 7.41 Ohm/km AC: 9.01 Ohm/km
Core Colours	Black/Red/Green/Yellow
Insulation Material	V-90 PVC
Insulation Thickness	0.7 mm
Insulation Resistance	12 MOhm/km
Overall Diameter	12.2 mm x 5.4 mm
Sheath Material	PVC
Sheath Thickness	1 mm
Sheath Colour	White
Standards	AS/NZS 1125 AS/NZS 5000.2
Stranding	7/0.67 mm
Temperature	90 deg C
Voltage	450-750 Volt
Conductor Size	2.5 mm
Number of Cores	2 Core + Earth
Earth Conductor Size	2.5 mm
