Olex 1.5mm Flat TPS Cable Red/Black/Green/Yellow 1mtr
Loading...
Description
Flat Twin & Earth Cable, 2 Core & Earth, 1.5 mm, Stranded Copper, 450/750 Volt, 1.5 mm Earth Conductor, 9.9 mm x 4.5 mm Overall Diameter, 0.6 mm Insulation Thickness, 0.9 mm Sheath Thickness, Conductor Resistance: DC: 13.6 Ohm/km, AC: 16.5 Ohm/km, Insulation Resistance: 14 MOhm/km, V-90 PVC Insulation, PVC Sheath, Red Black Green/Yellow Cores, White Sheath, 90 deg C, AS/NZS 1125, AS/NZS 5000.2
Key Specifications
| SKU |
OLX7/050-2ERBA15-150
|
|---|---|
| Brand |
Olex
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 150 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | CNCP05A1502WVAA |
