NHP Socket Outlet Surface Mounting Weatherproof 1Ph 15A 250V 3 Pin Flat Grey IP66

Description

Socket Outlet Weatherproof, 250 Volt, 15 Amp, 1 Phase Phase, Straight Angle, 3 Pin Flat, Screw Connection, 1.5-6 sq-mm Terminal Capacity, Surface Mounting, IP66, Polycarbonate, Grey, 107 mm Height, 101 mm Width, 91 mm Depth, Base Depth: 38 mm

Key Specifications

Barcode (EAN-13)	9321807200976
SKU	NHPISOSO315PG
Brand	NHP
Range Name	ISO
Product Type	Socket Outlets

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Large range covering 10 to 50 Amp in 3, 4 and 5 pin configurations High ingress protection of IP66 across the range User friendly design with extruded ribbed grips, large switch handle and large socket latches for easy operation with or without gloves Suitable for most industrial and commercial applications
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	ISOSO315PG
Colour	Grey
Angle	Straight
Connection Type	Screw
Current	15 Amp
Depth	91 mm
Height	107 mm
IP Rating	IP66
Material	Polycarbonate
Mounting Method	Surface
Phase	1 Phase
Pin Configuration	3 Pin Flat
Please Note	Base Depth: 38 mm
Terminal Capacity	1.5-6 sq-mm
Voltage	250 Volt
Width	101 mm
