NHP DIN-T RCBO Type A 240 VAC 10 Amp 10 kA 1 Pole + N 100 mA IP40 2 Module 35 mm

$NHP_DIN-T\NHP_DIN-T_RCBO-10kA-1P-06A.JPG$

Description

2 Pole RCBO suitable for new installation or for retrofit in either loadcentre's or panelboards. New blue earth leakage trip indicator (ETI), Red/Green contact position indicator (CPI) that is independent of the toggle position. High immunity Type AI in 30 mA as well as Type F in 30 mA for single phase complex loads such as frequency invertors, single phase invertors. Fast installation utilising standard 18mm pin busbar comb onto the bottom terminals or quick install into Concept distribution panelboards with compatible busbar chassis (2 and 4 Pole). Neutral on RH side

Key Specifications

Barcode (EAN-13)	8012542684053
SKU	NHPDTRD10100A
Brand	NHP DIN-T

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Standard AS/NZS 61009 Approval No NSW29318 and RCM Earth leakage protection Type A, AI or Type F Contact position indicator green/red flag (CPI) Shunt, UVT and Aux compatible Switched neutral
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DTRD10100A
Connection Type	Fork/Pin
Current	10 Amp
Colour	Grey
Depth	75 mm
Frequency	50/60 Hz
Height	85 mm
Modules	2 Module 35 mm
IP Rating	IP40
Mounting Method	DIN Rail
Interrupt Capacity	10 kA
Number Of Poles	1 Pole
Temperature	-25 to 70 deg C
Terminal Connection	1-35 sq-mm
Trip Sensitivity	100 mA
Width	35 mm
Voltage	240 Volt AC
Trip Characteristic	C Curve
