NHP DIN-T Miniature Circuit Breaker C Curve 240V 40A 6kA 1Pole 1Module 17.5mm DIN Rail Mount

$NHP_DIN-T\NHP_DIN-T_DTM6140C.jpg$

Description

High performance compact DIN circuit breaker suitable for either loadcentre's or panelboards, new red/green contact position indicator (CPI) that is independent of the toggle position. Fast installation utilising standard 18 mm pin busbar comb onto the bottom terminals or quick install into Concept distribution panelboards.

Key Specifications

Barcode (EAN-13)	4053546126631
SKU	NHPDTM6140C
Brand	NHP DIN-T
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	CPI indicator Safety terminal Pin or fork busbar comb Captive lock off LOCKDIN compatible AUX/AL, SHT & UVT compatible
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DTM6140C
Actuator Type	Toggle
Cable Size	0.75-35 sq-mm
Colour	Grey
Current	40 Amp
Depth	75 mm
Frequency	50/60 Hz
Height	85 mm
Interrupt Capacity	6 kA
IP Rating	IP40
Modules	1 Module 17.5 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Temperature	-25 to 70 deg C
Voltage	240 Volt AC / 65 Volt DC
Width	17.5 mm
