Std Pack Size
500
OUR P/N:
MMCCEB02PFIMB7/0.85B
Flat Twin & Earth Cable, 2 Core & Earth, 4 mm, Plain Annealed Copper, 450/750 Volt, 7/0.85 mm Strands, 2.6 mm Nominal Diameter, 2.5 mm Earth Conductor, 14.1 mm x 6.5 mm Overall Diameter, 30 mm Bend Radius, 0.8 mm Insulation Thickness, Conductor Resistance: DC: 4.61 Ohm/km, V-90 PVC Insulation, 3V-90 PVC Sheath, Red Black Green/Yellow Cores, Black Sheath, 90 deg C, AS/NZS 5000.2
Additional Information
| Brand | Prysmian |
|---|---|
| Standard Pack Size | 500 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 20200016 |
| Bend Radius | 30 mm |
| Conductor Type | Plain Annealed Copper |
| Conductor Resistance | DC: 4.61 Ohm/km |
| Core Colours | Red/Black/Green/Yellow |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.8 mm |
| Nominal Diameter | 2.6 mm |
| Overall Diameter | 14.1 mm x 6.5 mm |
| Product Type | Power Cable |
| Sheath Material | 3V-90 PVC |
| Sheath Colour | Black |
| Standards | AS/NZS 5000.2 |
| Stranding | 7/0.85 mm |
| Temperature | 90 deg C |
| Voltage | 450-750 Volt |
| Conductor Size | 4 mm |
| Number of Cores | 2 Core + Earth |
| Earth Conductor Size | 2.5 mm |
