Schneider Time Switch Digital 7 Day 1 Channel 230-240VAC 16A 10yr Reserve 1 Module CO DIN Rail Mount

$Schneider\Schneider_15331.jpg$

Description

Time Switch Digital 7 Day, 230-240 VAC, 16 Amp Switching Capacity, 0.5 W, 50-60 Hz, 1 Modules, 1 Channels, +/-1 sec/Day at 20 deg C Accuracy, Screw, 10 Years Reserve Battery Backup, CO, IP20, DIN Rail,-10 to 50 deg C, 90mm Height x 18mm Width x 66mm Depth

Key Specifications

Barcode (EAN-13)	3303430153313
SKU	MEG15331
Brand	Schneider
Product Type	Time Switches Digital

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	15331
Accuracy	+/-1 sec/Day at 20 deg C
Battery Backup	10 Years Reserve
Connection Type	Screw
Contact Type	Changeover
Dimensions	90 mm Height x 18 mm Width x 66 mm Depth
IP Rating	IP20
Frequency	50-60 Hz
Modules	1 Module
Number of Channels	1 Channel
Mounting Method	DIN Rail
Power Rating	0.5 Watt
Switching Capacity	16 Amp
Temperature	-10 to 50 deg C
Voltage	230-240 Volt
