Legrand Bootlace Ferrule Insulated Single with Flange 0.75mm 1.5x8mm Pin Blue 14.5mm OAL

$Legrand\Legrand_Starfix.jpg$

Description

Insulated Single Bootlace Ferrule, 0.75 mm, 2 Conductors, 8 mm Pin Length, 1.5 mm Pin Diameter, 3.4 mm Collar Inside Diameter, 14.5 mm Overall Length, Electro Grade Copper Sleeve, Polypropylene Insulation, Blue Insulation, Copper Contact, Tin Plated, 480 Pack, With Flange

Key Specifications

Barcode (EAN-13)	3245060376628
SKU	LEG37662
Brand	Legrand
Range Name	Starfix

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provide an equipotential link for all the strands of a flexible conductor
Standard Pack Size	1
UNSPSC Class	39121400
UOM	PK
Vendor Product	37662
Collar Inside Diameter	3.4 mm
Conductor Size	0.75 mm
Contact Material	Copper
Insulation Colour	Blue
Insulation Material	Polypropylene
Finish	Tin Plated
Overall Length	14.5 mm
Number of Conductors	2
Pin Diameter	1.5 mm
Pack Size	480 Pack
Please Note	with Flange
Pin Length	8 mm
Sleeve Material	Electro Grade Copper
