IDEC Miniature General Purpose Relay Plug-In Mount 2P DPDT 10A 12VDC 8 Pin Flat

$IDEC\IDEC_RH2B_Series.jpg$

Description

Miniature General Purpose Relay, 240 Volt AC, 12 Volt DC, 10 Amp, 0.9 Watt, 8 Pin Flat, 2 Pole, DPDT/2CO, 160 Ohm, Operating Time: 20 Operate/Release ms, Plug-In Mount, Silver Cadmium Oxide/Cadmium Free (Ag-alloy), -25 to 50 deg C, 27.5 mm Height, 42 mm Width, 21 mm Depth

Key Specifications

Barcode (EAN-13)	9322017188207
SKU	IDCRH2B-UDC12
Brand	IDEC
Range Name	RH Series
Product Type	Power Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Compact midget size saves space High switching capacity Without LED
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	RH2B-UDC12
Contact Configuration	DPDT/2 Changeover
Depth	21 mm
Contact Material	Silver Cadmium Oxide/Cadmium Free (Ag-alloy)
Current	10 Amp
Height	27.5 mm
Mounting Method	Plug In
Number Of Poles	2 Pole
Operating Coil Voltage	12 Volt DC
Operating Time	20 Operate/Release ms
Resistance	160 Ohm
Pin Configuration	8 Pin Flat
Power Rating	0.9 Watt
Temperature	-25 to 50 deg C
Voltage	240 Volt AC
Width	42 mm
