Heinelec Miniature Circuit Breaker 2 Pole 10 Amp 6 kA 2 Module 36mm DIN Rail Mount

Description

Miniature Circuit Breaker, 240/415 Volt, 10 Amp, 50/60 Hz, Interrupt Capacity: 6 kA, Number of Modules: 2, 36mm Module Width, Number of Poles: 2, 1, 3, Trip Characteristic: C Curve, Front Terminal, IP2X, DIN Rail, White, 30 deg C, 82.4mm Height x 36mm Width x 68mm Depth

Key Specifications

SKU	HEIQFD28210
Brand	Heinelec
Range Name	QF Range
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Precision circuit breaker utilizing hydraulic magnetic technology Always carry 100% of rated current. Trip point un-affected by ambient temperature Breaker can be immediately reclosed after tripping, once fault is cleared No cooling down time required thus saving time and testing. (No thermal memory) No ageing deterioration of sensing mechanism which is hermetically sealed Handle is sealable and padlockable (with padlock attachment) Suits HQFC chassis 250A rated RCBO is suitable for applications with pulsating DC components RCBO insulation resistance testing can be done with handle in the off position no disconnection of the unit is required
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	QFD28210
Colour	White
Current	10 Amp
Depth	68 mm
Frequency	50/60 Hz
Height	82.4 mm
Interrupt Capacity	6 kA
IP Rating	IP2X
Mounting Method	DIN Rail
Number Of Poles	2 Pole
Temperature	30 deg C
Terminal Type	Front
Voltage	240-415 Volt
Width	36 mm
