Hager Apex+ MCB Panelboard W/160A Main Switch Split Chassis Surface 18/24/18P 1.6mm Galvanised Steel X15 Orange IP43

Description

Modular MCB Panelboard, Split Chassis, 250 Amp, Number of Poles: 72 (18 Top, 24 Middle and 18 Bottom), Field Reversible Door, Surface, For Use With: DIN MCBs, IP43, 1.6mm Galvanised Steel, X15 Orange, Ripple Powder Coated, 1400mm Height x 600mm Width x 200mm Depth

Key Specifications

Barcode (EAN-13)	9329659007927
SKU	HAGJPD3W60S25DX
Brand	Hager
Range Name	Performa Apex Plus
Product Type	Panelboards MCB

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Galvanised steel gland plates as standard Split neutral and earth links with bridged neutrals Type tested chassis Choice of incomer switches or MCCB device 2 x 6 pole DIN Fault current rated at 20 kA for 0.2 sec Field reversible door and hinged escutcheon Flush handle with key lock Positive MCB alignment Safety pole fillers
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	JPD3W60S25DX
Colour	Orange
Configuration	DIN MCB
Dimensions	1400mm Height x 600mm Width x 200mm Depth
Door Type	Field Reversible
Current	250 Amp
Finish	Ripple Powder Coated
IP Rating	IP43
Mounting Method	Surface
Number Of Poles	72P
Material	1.6mm Galvanised Steel
