GSME Trader Flat Cat Switch Cover Plate Vertical 2 Gang 10AX/16A 250V White

$GSME\GSME_FLSWV2GMW.jpg$

Description

Switch Cover Plate, 250 Volt Switch, 16 Amp/10 Amp AX, 2 Gang, 2 Way, Screw Connection, Brass Tunnel Terminal, 4 x 1.5 sq-mm Terminal Capacity, Vertical Orientation, Wall Mounting, 84 mm Mounting Centres, UV Stabilised Polycarbonate, White, 116 mm Height, 76 mm Width, 26.5 mm Depth

Key Specifications

Barcode (EAN-13)	9349703023802
SKU	GSMFLSWV2GMW
Brand	GSME Trader
Range Name	Flat Cat
Product Type	Covers & Grids

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Switches are rated 10AX/16 Amp 250 Volt to and approved to AS/NZS3133 Fits recessed Australian wall boxes and mounting accessories that use 84 mm mounting centres Uses brass tunnel terminals that have the screws backed out for easier installation of cabling. Switches are two way with looping terminal and suit 4 x 1.5 sq-mm cabling with 4.1 mm bore Slotted head screws for the terminals Covers, plates and dollies are made from UV stabilised polycarbonate to avoid discolouring to yellow Plates suit Trader Meerkat MESW mechanisms including TV and data and Clipsal 30 style mechanisms and accessories
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	FLSWV2GMW
Colour	White
Connection Type	Screw
Current	16 Amp/10 Amp AX
Depth	26.5 mm
Height	116 mm
Material	UV Stabilised Polycarbonate
Mounting Centres	84 mm
Mounting Method	Wall
Number Of Gangs	2 Gang
Number Of Ways	2 Way
Orientation	Vertical
Terminal Capacity	4 x 1.5 sq-mm
Terminal Type	Brass Tunnel
Voltage	250 Volt Switch
Width	76 mm
