Garland Pro Series Instrumentation Cable Unarmoured 6 Triad Overall Screened 1.5mm 110/150V PVC/AL/PVC Black

$Garland\Garland_MCT7056S.jpg$

Description

Instrumentation Cable, Unarmoured, 6 Triad, Overall Screened, 1.5 mm, Plain Annealed Copper, 110/150 Volt, 7/0.5 mm Strands, 16 mm Overall Diameter, Bend Radius: Static - 160 mm, 0.3 mm Insulation Thickness, 1.2 mm Sheath Thickness, Elongation: Insulation - >100% Outer Sheath - >100%, 1490 N Pulling Tension, >12 MPa Tensile Strength, Conductor Resistance: DC - 13.6 Ohm/km, 100% Screen Coverage, Aluminium/Polyester Tape Screen, V-90HT PVC Insulation, 5V-90 PVC Sheath, Black White Red & Numbered Cores, Black Sheath, -15 to 90 deg C, AS/NZS 1125 , AS/NZS 3808 , IEC60332-1

Key Specifications

Barcode (EAN-13)	9329850000000
SKU	GARMCT7056S500
Brand	Garland
Product Type	Instrumentation Cable Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	MCT7056S500
Bend Radius	Static 160 mm
Conductor Size	1.5 mm
Conductor Type	Annealed Copper
Insulation Material	V-90HT PVC
Conductor Resistance	DC: 13.6 Ohm/km
Elongation	Insulation: >100% Outer Sheath: >100%
Number of Pairs	6 Triad
Insulation Thickness	0.3 mm
Overall Diameter	16 mm
Core Colours	Black/White/Red Numerals
Pulling Tension	1490 N
Screen Coverage	100%
Sheath Colour	Black
Screen Material	Aluminium/Polyester Tape
Sheath Thickness	1.2 mm
Standards	AS/NZS 1125 AS/NZS 3808 IEC60332-1
Screen Format	Overall Screened
Sheath Material	5V-90 PVC
Stranding	7/0.5 mm
Voltage	110-150 Volt
Tensile Strength	>12 MPa
Temperature	-15 to 90 deg C
