Finder Miniature General Purpose Relay Plug-In Mount 4P 4CO 7A 12VDC 14 Pin Flat

Description

Miniature General Purpose Relay, 250 Volt AC, 12 Volt DC Coil Voltage, 7 Amp, 0.125 kW, 14 Pin Flat, 4 Pole, 4 Changeover Configuration, 140 Ohm, 3 ms Breaking/11 ms making Operating Time, 150000 Cycles, Plug-In Mounting, Silver Nickel (Ag/Ni) Contact, -40 to 85 deg C, 27.7 mm Height, 20.7 mm Width, 36.7 mm Depth, With PB plus/LED plus/Mechanical Indicator

Key Specifications

Barcode (EAN-13)	8012823100968
SKU	FID55.34.007412VDC
Brand	Finder
Range Name	Series 55
Product Type	Power Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Complete range from PCB to power relays to cover all of your switching requirements Compact construction allowing for most efficient use of space Lockable test button and mechanical flag indicator as standard on 2 and 4 pole types
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	5534007412VDC
Contact Configuration	4 Changeover
Contact Material	Silver Nickel (Ag/Ni)
Current	7 Amp
Height	27.7 mm
Depth	36.7 mm
Mounting Method	Plug-In
Number Of Poles	4 Pole
Operating Coil Voltage	12 Volt DC
Please Note	With PB plus/LED plus/Mechanical Indicator
Operating Time	3 ms Breaking/11 ms making
Pin Configuration	14 Pin Flat
Operating Cycles	150000 Cycles
Temperature	-40 to 85 deg C
Power Rating	0.125 kW
Resistance	140 Ohm
Width	20.7 mm
Voltage	250 Volt AC
