Finder Miniature Relay Plug In Or Faston Connection 2P 2CO 8A 24VDC 8 Pin Flat

$Finder\Finder_4652.jpg$

Description

Miniature Relay, 250 Volt AC, 24 Volt DC Coil Voltage, 8 Amp, 0.37 kW, 8 Pin Flat, 2 Pole, 2 Changeover Configuration, 1200 Ohm, 3 ms Breaking/10 ms making Operating Time, 100000 Cycles, Plug-In/Faston Connection Mounting, Silver Nickel (Ag/Ni) Contact, -40 to 70 deg C, 32.8 mm Height, 29 mm Width, 12.4 mm Depth, With PB plus/LED plus/Mechanical Indicator

Key Specifications

Barcode (EAN-13)	8012823305097
SKU	FID46.52.007424VDC
Brand	Finder
Range Name	Series 46

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Complete range from PCB to power relays to cover all of your switching requirements Compact construction allowing for most efficient use of space
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	4652007424VDC
Contact Configuration	2 Changeover
Contact Material	Silver Nickel (Ag/Ni)
Current	8 Amp
Height	32.8 mm
Depth	12.4 mm
Mounting Method	Plug-In/Faston Connection
Number Of Poles	2 Pole
Operating Coil Voltage	24 Volt DC
Please Note	With PB plus/LED plus/Mechanical Indicator
Operating Time	3 ms Breaking/10 ms making
Pin Configuration	8 Pin Flat
Operating Cycles	100000 Cycles
Temperature	-40 to 70 deg C
Power Rating	0.37 kW
Resistance	1200 Ohm
Width	29 mm
Voltage	250 Volt AC
