Elcon 1.5mm Violet Flexible Wire Heavy Duty V90HT PVC

Description

Flexible Wire, Heavy Duty, 1.5 mm, Tinned Annealed Copper, 0.6-1 kV, 21 Amp, 1 Core, 30/0.25 mm Strands, 3.15 mm Overall Diameter, 0.8 mm Insulation Thickness, 13.7 MOhm/m Insulation Resistance, V-90HT PVC Insulation, Violet Insulation, Unsheathed, 90 deg C, AS/NZS 1125 AS/NZS 3808:2000 AS/NZS 3191

Key Specifications

SKU	ELNFHDT130025V100M
Brand	Elcon Cables

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RoHS Compliant Excellent flexibility UV resistant 99.9% OFHC (Oxygen Free High Conductivity) Copper which does not show any brittleness
Standard Pack Size	100
UNSPSC Class	26121500
UOM	MTR
Vendor Product	FHDT130025V100M
Conductor Type	Tinned Annealed Copper
Insulation Colour	Violet
Current	21 Amp
Insulation Material	V-90HT PVC
Insulation Thickness	0.8 mm
Insulation Resistance	13.7 MOhm/m
Overall Diameter	3.15 mm
Sheath Material	Unsheathed
Standards	AS/NZS 1125 AS/NZS 3808:2000 AS/NZS 3191
Stranding	30/0.25 mm
Temperature	90 deg C
Voltage	0.6-1 kV
Conductor Size	1.5 mm
Number of Cores	1 Core
