Elcon 2.5mm 2 Core + Earth Grey Flexible Cable V-90 PVC/Nitril Modified PVC (NBR)

Description

Flexible Cable, 2.5 mm, Annealed Copper, 250-440 Volt, 20 Amp, 2 Core + Earth, 50/0.25 mm Strands, 10 mm Overall Diameter, 0.8 mm Insulation Thickness, 1.1 mm Sheath Thickness, DC: 7.98 MOhm/km Insulation Resistance, Brown/Blue/Green/Yellow Core, V-90 PVC Insulation, Nitril Modified PVC (NBR) Sheath, Grey Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.1

Key Specifications

SKU	ELNCFMMFO350025S
Brand	Elcon Cables
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RoHS Compliant Approved by Electrical Safety Victoria (ESV) 3 Core Cables Certificate V4053 Excellent flexibility UV stabilised 99.9% OFHC (Oxygen Free High Conductivity) Copper which does not show any brittleness
Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CFMMFO350025S100M
Conductor Size	2.5 mm
Conductor Type	Annealed Copper
Core Colours	Brown/Blue/Green/Yellow
Current	20 Amp
Insulation Material	V-90 PVC
Insulation Resistance	7.98 MOhm/km
Insulation Thickness	0.8 mm
Number of Cores	2 Core + Earth
Overall Diameter	10 mm
Sheath Colour	Grey
Sheath Material	Nitrile Modified PVC (NBR)
Sheath Thickness	1.1 mm
Standards	AS/NZS 1125 AS/NZS 5000.1
Stranding	50/0.25 mm
Temperature	90 deg C
Voltage	250-440 Volt
