Tele Fonika H07 RN-F Heavy Duty Flexible Cable 2 Core 6mm 0.6/1kV Tinned Copper EPR/CPE Black

Description

Flexible Cable, Heavy Duty, 2 Core, 6 mm, Class 5 Tinned Copper, 0.6/1 kV, 15 mm Overall Diameter, Bend Radius: Static - 60 mm Flexible - 75 mm, EPR Insulation, CPE Sheath, Brown Blue Cores, Black Sheath, -40 to 90 deg C, AS/NZS 5000.1

Key Specifications

SKU	ELEG-023042
Brand	ElectCables
Range Name	H07 RN-F
Product Type	Flexible Cable Heavy Duty

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Submersible to 500 metres UV-resistant Flame retardant Oil resistant Tinned conductors
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	G-023042
Bend Radius	Static: 60 mm - Flexible: 75 mm
Conductor Size	6 mm
Conductor Type	Class 5 Tinned Copper
Core Colours	Brown/Blue
Insulation Material	Ethylene-Propylene Rubber (EPR)
Number of Cores	2 Core
Overall Diameter	15 mm
Sheath Colour	Black
Sheath Material	CPE
Standards	AS/NZS 5000.1
Temperature	-40 to 90 deg C
Voltage	0.6-1 kV
