IPD Fuse Link HRC Clip In Blade 630A 500VAC 120kA Class gG DIN Size 3
Loading...
Description
Fuse Link HRC Clip In Blade, 500 VAC, 630 Amp, Screw Connection, Interrupt Capacity: 120 kA, Class gG, 86mm Height x 70mm Width x 150mm Depth, DIN Size 3
Key Specifications
| Barcode (EAN-13) |
8430399002316
|
|---|---|
| SKU |
EEFNHG3-630
|
| Brand |
IPD
|
| Range Name |
NH DIN Fuses
|
| Product Type |
Fuse Links HRC Clip In
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | NHG3-630 |
| Current | 630 Amp |
| Connection Type | Screw |
| Dimensions | 86 mm Height x 70 mm Width x 150 mm Depth |
| Interrupt Capacity | 120 kA |
| Standard Reference | DIN Size 3 |
| Utilisation Category | Class gG |
| Voltage | 500 Volt AC |
