Helukabel JZ-500 Flexible Control Cable Unscreened 14 Core & Earth 0.75mm 0.3/0.5kV Copper PVC/PVC Grey

Description

Flexible Control Cable, Unscreened, 14 Core & Earth, 0.75 mm, BaredegCopper, 0.3/0.5 kV, 11.4 mm Overall Diameter, Bend Radius: Static - 45.6 mm Flexible - 85.5 mm, Insulation Resistance: 20 Mohm/km, PVC Insulation, PVC Sheath, Black with White Numbered Green/Yellow Cores, Grey RAL 7001 Sheath, Static - -40 to 80 deg C Flexible - -15 to 80 deg C, DIN VDE 0285-525-2-51, DIN EN 50525-2-51

Key Specifications

SKU	DKSCC15G0.75
Brand	Helukabel
Product Type	Flexible Control Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Flame retardant UV resistant Submersible to 500 metres Oil resistant Tinned conductors
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CC15G0.75
Bend Radius	Static: 45.6 mm - Flexible: 85.5 mm
Conductor Size	0.75 mm
Conductor Type	Bare Copper
Core Colours	Green/Yellow/Black/White Numerals
Insulation Material	PVC
Insulation Resistance	20 Mohm/km
Number of Cores	14 Core + Earth
Overall Diameter	11.4 mm
Sheath Colour	Grey
Sheath Material	PVC
Standards	DIN VDE 0285-525-2-51 DIN EN 50525-2-51
Temperature	Static: -40 to 80 deg C Flexible: -15 to 80 deg C
Voltage	0.3-0.5 kV
