CMP Products Metal Cable Gland Armoured General Purpose 40.4-53.1mm M50 IP68

Description

Metal Cable Gland, Armoured, General Purpose, M50, 20 mm Thread Length, 40.4 mm Min. Sheath OD, 53.1 mm Max. Sheath OD, 44.1 mm Max. Bedding OD, 2 mm Min. Armour Wire, 2.5 mm Max. Armour Wire, 70.1 mm Width Across Flats, 78.6 mm Width Across Corners, 70 mm Protrusion Length, IP68, Thermoplastic Elastomer Seal, Brass Body, Nickel Plated Finish, -60 to 150 deg C

Key Specifications

SKU	CMP50CWD1RA5/A
Brand	CMP Products
Product Type	Cable Glands Metal

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	High quality durable material Robust, heavy duty design Metal-to-metal armour clamping Direct and remote installation Controlled outer load retention seal Unique OSTG prevents overtightening Deluge proof EMC tested
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	50CWD1RA5/A
Finish	Nickel Plated
Body Material	Brass
IP Rating	IP68
Max. Armour Wire	2.5 mm
Max. Bedding OD	44.1 mm
Max. Sheath OD	53.1 mm
Min. Armour Wire	2 mm
Min. Sheath OD	40.4 mm
Protrusion Length	70 mm
Temperature	-60 to 150 deg C
Seal Material	Thermoplastic Elastomer
Thread Length	20 mm
Thread Size	M50
Width Across Flats	70.1 mm
Width Across Corners	78.6 mm
