CMP Products Flame Proof Cable Gland Armoured 9.5-15.9mm M20 IP68

$CMP_Products\CMP_T3CDS_Explosive_Atmosphere.jpg$

Description

Hazardous Area Cable Gland Armoured Flame Proof, M20, 15 mm Thread Length, 9.5 mm Min. Sheath OD, 15.9 mm Max. Sheath OD, 11.6 mm Max. Bedding OD, 0.8 mm Min. Armour Wire, 1.2 mm Max. Armour Wire, Exd IIC Gb, Exe IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Exd I Mb, Exe I Mb, 24 mm Width Across Flats, 26.4 mm Width Across Corners, 78.7 mm Protrusion Length, IP68, Brass Body, Thermoset Elastomer Seal, Nickel Plated, -60 to 30 deg C

Key Specifications

SKU	CMP20ST3CDS1RA5
Brand	CMP Products
Range Name	Triton CDS T3CDS
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Fully sequential, three step installation procedure Reduces installation times, cost and risk Direct and remote installation Unique compensating displacement seal system - metal-to-metal installation every time regardless of cable diameter Designed to prevent cold flow Integral protected deluge seal Controlled outer load retention seal Unique OSTG prevents overtightening EMC tested
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	20ST3CDS1RA5
Finish	Nickel Plated
Body Material	Brass
Hazardous Area Rating	Exd IIC Gb Exe IIC Gb Ex nR IIC Gc Ex ta IIIC Da Exd I Mb Exe I Mb
IP Rating	IP68
Max. Armour Wire	1.2 mm
Min. Armour Wire	0.8 mm
Max. Bedding OD	11.6 mm
Min. Sheath OD	9.5 mm
Max. Sheath OD	15.9 mm
Protrusion Length	78.7 mm
Seal Material	Thermoset Elastomer
Temperature	-60 to 30 deg C
Thread Length	15 mm
Thread Size	M20
Width Across Corners	26.4 mm
Width Across Flats	24 mm
