CMP Products Flame Proof Cable Gland Armoured 9.5-15.9mm M20 IP66

$CMP_Products\CMP_Products_Type_E1FW_Gland.jpg$

Description

Hazardous Area Cable Gland Armoured Flame Proof, M20, 15 mm Thread Length, 9.5 mm Min. Sheath OD, 15.9 mm Max. Sheath OD, 11.7 mm Max. Bedding OD, 0.8 mm Min. Armour Wire, 1.25 mm Max. Armour Wire, Exd IIC, Exe II, Ex nR II, Ex tD A21 IP66, Exd I, Exe I, 24 mm Width Across Flats, 26.6 mm Width Across Corners, 58.5 mm Protrusion Length, IP66, Brass Body, Thermoset Elastomer Seal, Nickel Plated, -60 to 130 deg C

Key Specifications

SKU	CMP20SE1FW1RA5
Brand	CMP Products
Range Name	Type E1FW
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Metal-to-metal armour clamping Direct and remote installation Displacement type flameproof inner seal Controlled outer 'load retention' seal Unique OSTG prevents overtightening Designed to prevent cold flow EMC tested
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	20SE1FW1RA5
Body Material	Brass
Finish	Nickel Plated
Hazardous Area Rating	Exd IIC Exe II Ex nR II Ex tD A21 IP66 Exd I Exe I
IP Rating	IP66
Protrusion Length	58.5 mm
Max. Bedding OD	11.7 mm
Max. Sheath OD	15.9 mm
Min. Sheath OD	9.5 mm
Min. Armour Wire	0.8 mm
Max. Armour Wire	1.25 mm
Seal Material	Thermoset Elastomer
Temperature	-60 to 130 deg C
Thread Size	M20
Width Across Corners	26.6 mm
Width Across Flats	24 mm
Thread Length	15 mm
