CMI 25mm Black Circular Cable Unarmoured X-90 XLPE/5V-90 PVC 1mtr

Description

Circular Cable Unarmoured, 25mm, Annealed Copper, 0.6-1 kV, 4 Core + Earth, 19/1.35mm Strands, 5.7mm Nominal Diameter, 23.5mm Overall Diameter, 6mm Earth Conductor, 1 mtr Length, 0.9mm Insulation Thickness, 1.8mm Sheath Thickness, Red/White/Blue/Black/Green/Yellow Core, X-90 XLPE Insulation, 5V-90 PVC Sheath, Black Sheath, AS/NZS 1125 AS/NZS 3808

Key Specifications

SKU	CMIOX19135C4CE
Brand	CMI
Product Type	Circular Cable Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	OX19135C4CE
Conductor Size	25 mm
Conductor Type	Annealed Copper
Core Colours	Black/Blue/Red/White/Green/Yellow
Insulation Thickness	0.9 mm
Insulation Material	X-90 XLPE
Earth Conductor Size	6 mm
Nominal Diameter	5.7 mm
Number of Cores	4 Core + Earth
Overall Diameter	23.5 mm
Sheath Colour	Black
Sheath Material	5V-90 PVC
Sheath Thickness	1.8 mm
Stranding	19/1.35 mm
Standards	AS/NZS 1125 AS/NZS 3808
Voltage	0.6-1 kV
