Clipsal C-Bus PIR Occupancy Sensor Outdoor Surface/Wall/Ceiling Mount 110deg IP66 Grey

Description

PIR Occupancy Sensor, 15-36 Volt DC, 18 mA, PIR Sensing Method, Lateral: 12 mtr/Frontal: 18 mtr Sensing Range, 110 deg Sensing Beam, 2.4 mtr Mounting Height, IP66, Wall/Ceiling Mounting, Plastic, Grey, 0 to 45 deg C, 74 mm Width x 111 mm Height x 138 mm Depth, 84 mm Mounting Centre

Key Specifications

Barcode (EAN-13)	9311554347772
SKU	CLI5750WPLGY
Brand	Clipsal
Range Name	C-Bus
Product Type	Sensors

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	C-bus PIR motion detector suitable for outdoor use The unit has a field of view of 110 deg and a detection range which extends 18 mtr The unit features a light threshold adjustment on the unit The time delay is programmable in the range 1 sec-18 hrs Features a sunset switch program Draws 18 mA from a C-bus network 1 channel Light sensitivity adjustable setting 1 lux user selectable Non-volatile memory
Standard Pack Size	1
UNSPSC Class	39121800
UOM	EA
Vendor Product	5750WPL-GY
Colour	Grey
Current	18 mA
Dimensions	74 mm Width x 111 mm Height x 138 mm Depth
IP Rating	IP66
Mounting Height	2.4 mtr
Mounting Method	Wall/Ceiling
Material	Plastic
Please Note	84 mm Mounting Centre
Sensing Beam	110 deg
Sensing Range	Lateral: 12 mtr / Frontal: 18 mtr
Sensing Method	PIR
Temperature	0 to 45 deg C
Voltage	15-36 Volt DC
