Clipsal 56 Series Socket Outlet Surface Mounting RCD Protected 3Ph 20A 500V 4 Pin Round 30mA Grey IP66

$ClipsalNew\C0002466-GY.png$

Description

Socket Outlet Surface Mounting RCD Protected, 3 Phase, 20 Amp, 500 Volt AC, 4 Pole, 3 Gang, 4 Pin Round, Trip Sensitivity: 30 mA, Screw, Terminal Capacity: 1.5 to 16 mm, Surface Mount, IP66, Polycarbonate, Grey, 294 mm Height, 101 mm Width, 110 mm Depth, -25 to 75 deg C

Key Specifications

Barcode (EAN-13)	9311554276942
SKU	CLI56C420RCGY
Brand	Clipsal
Range Name	56 Series
Product Type	Socket Outlets RCD Protected

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	56C420RC-GY
Colour	Grey
Connection Type	Screw
Current	20 Amp
Depth	110 mm
Height	294 mm
IP Rating	IP66
Mounting Method	Surface
Number Of Gangs	3 Gang
Phase	3 Phase
Pin Configuration	4 Pin Round
Number Of Poles	4 Pole
Temperature	-25 to 75 deg C
Terminal Capacity	1.5-16 mm
Trip Sensitivity	30 mA
Voltage	500 Volt
Width	101 mm
