2.5mm Orange Circular Cable Unarmoured PVC/PVC 500mtr

$Prysmian\Prysmian_Unarmoured_2C-E.jpg$

Description

Circular Cable Unarmoured, 2.5mm, Annealed Copper, 0.6-1 kV, 2 Core + Earth, 7/0.67mm Strands, 2mm Nominal Diameter, 11.7mm Overall Diameter, 2.5mm Earth Conductor, 100 mtr Length, 50mm Bend Radius, 0.8mm Insulation Thickness, DC: 7.41 Ohm/km Conductor Resistance, Red/Black/Green/Yellow Core, PVC Insulation, PVC Sheath, Orange Sheath, 75 deg C, AS/NZS 5000.1

Key Specifications

Barcode (EAN-13)	9310835058390
SKU	CBL2.5/2CEOC1KV-5
Brand	Generic
Product Type	Circular Cable Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	20199551
Conductor Resistance	DC: 7.41 Ohm/km
Bend Radius	50 mm
Conductor Size	2.5 mm
Core Colours	Black/Red/Green/Yellow
Conductor Type	Annealed Copper
Earth Conductor Size	2.5 mm
Insulation Material	PVC
Insulation Thickness	0.8 mm
Nominal Diameter	2 mm
Number of Cores	2 Core + Earth
Overall Diameter	11.7 mm
Sheath Colour	Orange
Sheath Material	PVC
Standards	AS/NZS 5000.1
Stranding	7/0.67 mm
Temperature	75 deg C
Voltage	0.6-1 kV
