Cabac Circuit Breaker Lug 95mm 8mm Stud Bi-Metal

$Cabac\Cabac_BL95CB-8.jpg$

Description

Bi-Metal Circuit Breaker Lug, 95 mm, 8 mm Stud, 60 mm Barrel Length, 105 mm Overall Length, 1 Hole, 13.5 mm Inside Diameter, 20 mm Lug Width, 22.5 mm Lug Length, 4 mm Lug Thickness, 17.3 mm A-F Hex Die, HT-95/120AL, 2 Crimps, Aluminium/Copper Body, Aluminium/Copper

Key Specifications

Barcode (EAN-13)	9318674781615
SKU	CAABL95CB-8
Brand	Cabac

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Manufactured using friction welding process producing a very strong electrically sound joint Suitable for aluminium conductor and copper circuit breaker terminals Crimp from palm end to force compound into conductor strands Crimping compound in barrel and sealed with cap Crimping positions, AF, clearly marked on barrel
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	BL95CB-8
A-F Hex Die	17.3 mm
Barrel Length	60 mm
Body Material	Aluminium/Copper
Conductive Material	Aluminium/Copper
Conductor Size	95 mm
Crimping Die	HT-95/120AL
Inside Diameter	13.5 mm
Lug Length	22.5 mm
Lug Thickness	4 mm
Lug Width	20 mm
Number of Crimps	2
Number of Holes	1 Hole
Overall Length	105 mm
Stud Size	8 mm
