Cabac Crimp Lug Stalk Aluminium 95mm M12 Stud 37mm L Stalk 110mm OAL

Description

Crimp Lug, Stalk Aluminium, 95 mm Conductor, 13.5mm Inside Diameter, M12 Stalk, 37mm Stalk Length, 110 mm Length, 60mm Barrel, Aluminium Body, Aluminium Conductor, Number of Strands: 37/1.78, A/F Hex Die: 17.3 mm, Crimping Die: HT-95/120AL, 2 Crimps

Key Specifications

Barcode (EAN-13)	9359736011400
SKU	CAAAS95/12
Brand	Cabac
Range Name	Stalk Lugs
Product Type	Crimp Lug Stalk Type

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Stalk lugs are generally used to attach aluminium cable to aluminium overhead conductor Suitable for electrical equipment with aluminium clamp terminals Crimped with CABAC standard tooling and dies for aluminium lugs
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	AS95/12
A-F Hex Die	17.3 mm
Barrel Length	60 mm
Body Material	Aluminium
Conductive Material	Aluminium
Conductor Size	95 mm
Crimping Die	HT-95/120AL
Inside Diameter	13.5 mm
Number of Crimps	2
Number of Strands	37/1.78
Overall Length	110 mm
Stalk Diameter	M12 Stalk
Stalk Length	37 mm
