Bussmann Fuse Link HRC Bolt In Centre 125 Amp 660 to 690VAC/350VDC 80 kA at 690VAC Class gG BS88 Type B1
Loading...
Description
Fuse Link HRC Bolt In Centre, 660 to 690 VAC/350 VDC, 125 Amp, Class gG, Interrupt Capacity: 80 kA at 690 VAC, 111mm Fixing Centres, Bolt In Centre Tag, 33.7mm Diameter x 136.5mm Length, BS88 Type B1
Key Specifications
| SKU |
BUSTF125
|
|---|---|
| Brand |
Bussmann
|
| Product Type |
Fuse Links HRC
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | TF125 |
| Fixing Centres | 111 mm |
| Dimensions | 33.7 mm Diameter x 136.5 mm Length |
| Current | 125 Amp |
| Interrupt Capacity | 80 kA |
| Standard Reference | BS88 Type B1 |
| Tag Type | Bolt In Centre |
| Utilisation Category | Class gG |
| Voltage | 660-690 Volt AC/350 Volt DC |
