Bambach High Temperature Flexible Wire Single Insulated 1 Core 1mm 0.6/1kV Silicone +200C White

Description

Flexible Wire, Single Insulated, High Temperature, 1 Core, 1 mm, Class 5 Tinned Annealed Copper, 0.6/1 kV, 28 Amp, 32/0.2 mm Strands, 3.3 mm Overall Diameter, R-S-200 Silicone Rubber Insulation, Unsheathed, White Insulation, -50 to 200 deg C, AS/NZS 1125, AS/NZS 3808, AS/NZS 3191, AS/NZS 5000.1, IEC 60228

Key Specifications

SKU	BAM15105WE
Brand	Bambach
Product Type	Flexible Cable High Temperature

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	R-S-200 insulation has a very wide operating range between -50 deg C and + 200 deg C Oxygen free tinned copper conductors provide excellent corrosion resistance at elevated temperatures Silicone rubber exhibits excellent electrical resistance Good flame retardance with zero halogens Halogen Free Silicone rubber insulation does not release corrosive gases when ignited Tinned Copper for Corrosion Resistance Low Temperature Resistance Minimum Recommended Bend Radius Fixed 6 x OD UV Resistant Wide Temperature Range Silicone rubber insulation is suitable in extreme high and low temperatures
Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	15105WE
Conductor Type	Class 5 Tinned Copper
Conductor Size	1 mm
Current	28 Amp
Insulation Material	R-S-200 Silicone Rubber
Insulation Colour	White
Overall Diameter	3.3 mm
Number of Cores	1 Core
Sheath Material	Unsheathed
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 3191 AS/NZS 5000.1 IEC 60228
Stranding	32/0.2 mm
Temperature	-50 to 200 deg C
Voltage	0.6-1 kV
