APEC 16mm SDI Cable 1mtr
Loading...
Description
Electrical Cable, 16 mm, Annealed Copper Conductor, 0.6/1 kV, 1 Core, 5.1 mm Nominal Diameter, 10.14 mm Overall Diameter, Bend Radius: 60.84 mm, 1 mm Insulation Thickness, 1.4 mm Sheath Thickness, 1.12 kN Pulling Tension, 1.15 Ohm/km Conductor Resistance, 40 GigaOhm/mtr Insulation Resistance, PVC Insulation, Black Insulation, PVC Sheath, Black Sheath, -25 to 90 deg C, AS/NZS 5000.1
Key Specifications
| Barcode (EAN-13) |
932666301483
|
|---|---|
| SKU |
APEVVM0165K1BB
|
| Brand |
APEC
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | VVM0165K1BB |
Downloads
Have questions about the product?
Do you need more information? We are here to help. Click below to contact us now!
