APEC 1.5 mm Black Circular Control Cable Unarmoured V-90 PVC/5V-90 PVC 100mtr
Loading...
Description
Circular Control Cable, Unarmoured, 1.5 mm, Annealed Copper, 0.6-1 kV, 4 Core + Earth, 7/0.5 mm Strands, 12.8 mm Overall Diameter, 1.5 mm Earth Conductor, 100 mtr Length, 0.8 mm Insulation Thickness, 1.8 mm Sheath Thickness, White Numerals/Green/Yellow Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, 90 deg C, AS/NZS 5000.1
Key Specifications
| Barcode (EAN-13) |
932666301007
|
|---|---|
| SKU |
APEVCM105E04B5K1
|
| Brand |
APEC
|
| Product Type |
Circular Control Unarmoured
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 100 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | VCM105E04B5K1 |
| Conductor Size | 1.5 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Green/Yellow/White Numerals |
| Earth Conductor Size | 1.5 mm |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.8 mm |
| Number of Cores | 4 Core + Earth |
| Overall Diameter | 12.8 mm |
| Sheath Colour | Black |
| Standards | AS/NZS 5000.1 |
| Sheath Thickness | 1.8 mm |
| Sheath Material | 5V-90 PVC |
| Stranding | 7/0.5 mm |
| Temperature | 90 deg C |
| Voltage | 0.6-1 kV |
