APEC Instrumentation Cable Unarmoured 1 Pair Overall Screened 1.5mm 0.3kV PVC/PVC Black
Loading...
Description
Instrumentation Cable Unarmoured, 1.5 mm, Annealed Copper, 0.3 kV, 1 Pair, 7/0.5 mm Strands, Overall Screened Screen, 6.1 mm Overall Diameter, 0.4 mm Insulation Thickness, Black/White Numerals Core, PVC Insulation, PVC LSZH Sheath, Black Sheath, UL 2464
Key Specifications
| Barcode (EAN-13) |
932666301154
|
|---|---|
| SKU |
APEINSO105P01B
|
| Brand |
APEC
|
| Product Type |
Instrumentation Cable Unarmoured
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | INSO105P01B |
| Conductor Size | 1.5 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Black/White Numerals |
| Insulation Material | PVC |
| Number of Pairs | 1 Pair |
| Insulation Thickness | 0.4 mm |
| Overall Diameter | 6.1 mm |
| Screen Format | Overall Screened |
| Sheath Colour | Black |
| Sheath Material | PVC LSZH |
| Standards | UL 2464 |
| Stranding | 7/0.5 mm |
| Voltage | 0.3 kV |
