Connectwell Rail Terminal Block Screwed Clamp 2 Wire 16mm Grey Polyamide 66

Description

16 mm Feed Through Terminal Blocks are the most Versatile terminals for control, Automation, Instrumentation and Power Distribution applications. A specially designed flexible foot enable easy mounting and dismounting from the DIN rail with the help of screw driver. These Terminal Blocks have marker holding recesses to accept marking tags for circuit identification. Cross connection can be achieved with the aid of shorting links/sleeves and screws.

Key Specifications

SKU	ALSCTS16U
Brand	Connectwell
Product Type	Rail Terminal Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	CTS16U
Colour	Grey
Conductor Size	0.2-16mm
Current Rating	76 Amp
Depth	12 mm
Height	52.8 mm/55.5 mm/47.8 mm
Insulation Material	Polyamide 66
Mounting Method	DIN 32/35/35-15
Number of Conductors	2
Number of Levels	1
Rated Surge Voltage	8 kV
Terminal Type	Screw Clamp
Tightening Torque	1.2 Nm
Voltage Rating	1000 Volt
Width	43 mm
Wire Entry Orientation	Side
Wire Strip Length	12 mm
Wiring Format	2 Conductor Through
