WWC 24 AWG 6 Pair Mist Grey Data Cable Overall Screened Polypropylene/PVC

Description

Data Cable, 24 AWG, Class 2 Tinned Annealed Copper, 0.3 kV, 6 Pair, 7/0.2 mm Strands, Overall Screened Screen, 7.6 mm Overall Diameter, 48 mm Bend Radius, 0.3 mm Insulation Thickness, DC: 10 Ohm/100m Conductor Resistance, 100% Screen Coverage, Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire Screen, Polypropylene Insulation, 4V-75 PVC Sheath, Mist Grey Sheath, -15 to 105 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1 UL 2493

Key Specifications

SKU	WWC4006
Brand	WWC
Product Type	Data Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	4006
Bend Radius	48 mm
Conductor Resistance	DC: 10 Ohm/100m
Conductor Size	24 AWG
Conductor Type	Class 2 Tinned Annealed Copper
Insulation Material	Polypropylene
Insulation Thickness	0.3 mm
Number of Pairs	6 Pair
Overall Diameter	7.6 mm
Screen Coverage	100%
Screen Format	Overall Screened
Screen Material	Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire
Sheath Colour	Mist Grey
Sheath Material	4V-75 PVC
Temperature	-15 to 105 deg C
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1 UL 2493
Stranding	7/0.2 mm
Voltage	0.3 kV
