Treotham 6mm SDI Cable 1mtr

chevron-left
loader
Loading...

Description

chevron-down
Flexible Cable, Double Insulated, 1 Core, 630 mm, Class 6 Stranded Annealed Copper, 0.6/1 kV, 1493 Amp, 5015/0.4 mm Strands, 46 mm Overall Diameter, 276 mm Bend Radius, Conductor Resistance: 0.029 Ohm/km, R-E-110 Insulation, R-HF-110 Sheath, White Insulation, Orange Sheath, -40 to 110 deg C, AS/NZS 1125, AS/NZS 3808, IEC60332-1, AS/NZS 5000.1

Key Specifications

chevron-down
SKU
TRETA7.6300.01.OE
Brand
Treotham

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Low Smoke Halogen Free (LSHF, LS0H, LSZH)
  • UV resistant
  • Flame Retardant
  • Resistant to: oils, petrol, acids, sea water
  • Submersible to 200 metres
Standard Pack Size 1
UNSPSC Class 26121600
UOM MTR
Vendor Product TA7.6300.01.OE
