Olex Speaker Cable 2 Core Figure 8 0.75mm 250/440V PVC/PVC Parallel Webbed Grey
Loading...
Description
Speaker Cable, 2 Core, Figure 8, 0.75 mm, Bare Copper, 250/440 Volt, 24/0.2 mm Strands, 5.9 mm x 2.9 mm Overall Diameter, 0.8 mm Insulation Thickness, Conductor Resistance: DC - 26 Ohm/km, PVC Insulation, Parallel Webbed, PVC Sheath, Grey Sheath
Key Specifications
| Barcode (EAN-13) |
9322576232595
|
|---|---|
| SKU |
OLXJSF75GY1
|
| Brand |
Olex
|
| Product Type |
Speaker Cable Figure 8
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | JSF.75GY1 |
| Conductor Resistance | DC: 26 Ohm/km |
| Conductor Size | 0.75 mm |
| Conductor Type | Bare Copper |
| Insulation Material | PVC |
| Insulation Thickness | 0.8 mm |
| Number of Cores | 2 Core |
| Overall Diameter | 5.9 mm x 2.9 mm |
| Sheath Colour | Grey |
| Sheath Material | PVC Parallel Webbed |
| Stranding | 24/0.2 mm |
| Voltage | 250-440 Volt |
