Olex Varolex Rigid VSD/EMC Cable Screened 3 Core & 3 Earth 70mm 0.6/1kV Stranded Copper XLPE/Copper Tape/PVC Black

Description

Rigid VSD/EMC Cable, Screened, 3 Core & 3 Earth, 70 mm, Stranded Copper, 0.6/1 kV, 19/2.14 mm Strands, 30 mm Earth Conductor, 32 mm Overall Diameter, 1.1 mm Insulation Thickness, Conductor Resistance: DC - 0.268 Ohm/km AC - 0.343 Ohm/km, Insulation Resistance: 270.5 MOhm/km, Copper Tape Screen, X-90 XLPE Insulation, PVC Sheath, Red Blue White Green/Yellow Cores, Black Sheath, 90 deg C, AS/NZS 1125, AS/NZS 5000.1

Key Specifications

Barcode (EAN-13)	99319215325087
SKU	OLX19/214-3EVAA9
Brand	Olex
Product Type	VSD/EMC Cable Rigid

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	FTDC20AA003CXRJ
Conductor Resistance	DC: 0.268 Ohm/km AC: 0.343 Ohm/km
Conductor Size	70 mm
Conductor Type	Stranded Copper
Core Colours	Red/Blue/White/Green/Yellow
Earth Conductor Size	6 mm
Insulation Material	X-90 XLPE
Insulation Resistance	270.5 MOhm/km
Insulation Thickness	1.1 mm
Number of Cores	3 Core + Earth
Overall Diameter	32 mm
Screen Material	Copper Tape
Sheath Colour	Black
Sheath Material	PVC
Standards	AS/NZS 1125 AS/NZS 5000.1
Stranding	19/2.14 mm
Temperature	90 deg C
Voltage	0.6-1 kV
