CMI 2.5 mm Black Circular Control Cable Unarmoured V-90 PVC/5V-90 PVC 1mtr
Loading...
Description
Circular Control Cable, Unarmoured, 2.5 mm, Annealed Copper, 0.6-1 kV, 20 Core + Earth, 7/0.67 mm Strands, 2 mm Nominal Diameter, 22.8 mm Overall Diameter, 2.5 mm Earth Conductor, 1 mtr Length, 0.8 mm Insulation Thickness, 1.8 mm Sheath Thickness, White Numerals/Green/Yellow Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, AS/NZS 1125 AS/NZS 3808
Key Specifications
| SKU |
CMICC7067C20CEBK
|
|---|---|
| Brand |
CMI
|
| Product Type |
Circular Control Unarmoured
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | CC7067C20CEBK |
| Conductor Size | 2.5 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Green/Yellow/White Numerals |
| Earth Conductor Size | 2.5 mm |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.8 mm |
| Nominal Diameter | 2 mm |
| Number of Cores | 20 Core + Earth |
| Overall Diameter | 22.8 mm |
| Sheath Colour | Black |
| Standards | AS/NZS 1125 AS/NZS 3808 |
| Sheath Thickness | 1.8 mm |
| Sheath Material | 5V-90 PVC |
| Stranding | 7/0.67 mm |
| Voltage | 0.6-1 kV |
